HMC Machines

MAKE	MODEL	QTY	SPECIFICATION
Makino	a51nx	2 Nos	Pallet size -400mm, Travel-813 x 508 x 711mm Capacity full 4th-300kg, HSK A63; 12000 RPM

MAKE	MODEL	QTY	SPECIFICATION
HASS	EC500	1 No	Pallet size -500mm, Travel-813 x 508 x 711mm Capacity full 4th-300kg,BT40m; 8000 RPM

MAKE	MODEL	QTY	SPECIFICATION
HASS	EC300	1 No	Pallet size -300mm, Travel-508 x 457 x 356mm Capacity full 4th-249kg, BT40m; 12000 RPM

MAKE	MODEL	QTY	SPECIFICATION
TAL	V500+	10 No	Bed size - 1020x660x600 mm, BT40m; 8000 RPM

MAKE	MODEL	QTY	SPECIFICATION
TAL	V450+	1 No	Bed size - 1020x660x600 mm, BT40m; 10000 RPM

MAKE	MODEL	QTY	SPECIFICATION
TAL	V400	2 Nos	Bed size - 610x410x500 mm, BT40m; 8000 RPM

MAKE	MODEL	QTY	SPECIFICATION
TAL	V500+	1 No	Bed size - 1020x660x600 mm, BT50m; 4000 RPM

MAKE	MODEL	QTY	SPECIFICATION
TAL	V650+	2 Nos	Bed size - 1020x660x600 mm, BT40m; 10000 RPM

HTC Machines

MAKE	MODEL	QTY	SPECIFICATION
LMV	LL25TL7	1 No	Max Dia - 320 mm Max Length - 725mm, Quill Move -125 mm

MAKE	MODEL	QTY	SPECIFICATION
LMW	LL25TL5	1 No	Max Dia - 320 mm Max Length - 560mm, Quill Move -100 mm

MAKE	MODEL	QTY	SPECIFICATION
Bilz	ISG3400	1 No	Dia: 3- 32 mm, Power: 12 kW, Cooling: Direct water cooled

Manual CMM

MAKE	MODEL	QTY	SPECIFICATION
Tesa	Tesa	1 No	460 x 510 x 420 mm; LC 0.001 mm

Other Equipments

• Vernier Height Gauge: 4 Nos
• Roughness Tester: 1 Nos
• Vernier Caliper: 15 Nos
• Micrometer: 11 Nos
• Bore Dial Gauge: 6 Nos
• Slip Gauge: 1 Set

Auto CMM

MAKE	MODEL	QTY	SPECIFICATION
Accurate	Spectra	1 No	1000 x 1000 x 800 mm; LC 0.001 mm

Tool Pre-setter

MAKE	MODEL	QTY	SPECIFICATION
Zoller	Compact	1 No	Dia: 300 mm, Height: 400 mm, Least Count: 0.001 mm

MAKE	MODEL	QTY	SPECIFICATION
Cummins	Powerica	1 No	250 kVA

MAKE	MODEL	QTY	SPECIFICATION
Chicago	CPC 50 IVR	1 No	2000 ltrs

MAKE	MODEL	QTY	SPECIFICATION
Chicago	CPA 15	1 No	500 ltrs
